The DM7000 Biphasic Defibrillator with monitor function is designed to meet all clinical requirements from Basic Life Support (BLS) to Advanced Cardiac Life Support (ACLS).
Display & Visuals
7 inch high resolution LCD display; Sweep Speed: 25mm/sec; Displays HR, Lead/Pads, Alarm Status, SpO2, AED Functions, and Delivered Energy.
Defibrillator Features
Waveform: Biphasic; Charge Time: Less than 7 seconds with new battery; Energy Display: Indicators for both selected and delivered energy; Prompt Type: Voice and visual prompts.
ECG Monitoring
Connection via 5-lead/3-lead cable or paddles; Lead Selection: I, II, III, AVR, AVL, AVF, V; Heart Rate Range: 20-300BPM with user-selectable Smart Alarms.
SpO2 Module
Measurement Range: 30~100%; Accuracy: ±2% (80%~90%); User-definable alarm limits for high and low range.
Thermal Recorder
50mm thermal paper; Selectable speeds (12.5, 25, 50mm/sec); Automatic 9-second recording initiated by alarms or discharge.
AED Mode
Auto analyze and programmable energy selection; Voice and visual prompts; Detects Ventricular Fibrillation and Ventricular Tachycardia.
Manual Mode
Energy Selection: 2, 5, 7, 10, 20, 30, 50, 70, 100, 150, 200, 300, 360 Joules; Synchronized Mode available (SYNC message displayed).
Frequently Asked Questions
What waveform does the DM7000 use for defibrillation?
The DM7000 utilizes a Biphasic waveform, which is the current clinical standard for effective cardiac resuscitation.
How fast can the device charge to maximum energy?
The device can charge to 200 Joules in approximately 8 seconds and is ready to deliver 360 Joules in manual mode within a very short timeframe.
What is the battery life during continuous monitoring?
A new, fully charged Ni-MH battery provides a minimum of 3 hours of continuous ECG monitoring or up to 60 discharges at maximum energy.
Can the DM7000 perform synchronized cardioversion?
Yes, the device features a Synchronized Mode that aligns the defibrillator pulse with the patient's R-wave, displaying a "SYNC" message on the monitor.
What parameters are tracked by the built-in monitor?
The 7-inch high-resolution screen displays Heart Rate (HR), SpO2 levels, ECG leads, AED prompts, alarm settings, and the actual energy delivered.
Does the unit include a printer for medical records?
Yes, it includes a high-resolution thermal recorder that can automatically print a 9-second recording upon alarm activation or defibrillator discharge.
